MX0104A Performance Verification and Deskew Fixture for InfiniiMax Probes

Product Overview

Features

50 Ω thru fixture for probe calibration, deskew and performance verification

Excellent signal integrity up to 40 GHz

2.92 mm male input and 3.5 mm male output

Recommended for use with InfiniiMax III, III+ probe amplifiers and probes

The MX0104A Performance Verification and Deskew Fixture is a 50 Ω thru fixture that enables calibration and deskew of InfiniiMax III/III+ Series probe amplifiers or verification of the probe's performance using a VNA. This fixture has excellent signal integrity up to 40 GHz. MX0104A is the replacement for N5443A. For bandwidths less than 13 GHz, the E2655C is required.

The MX0104A only includes a 50 Ω thru clamp. You can choose the Option 001 Plastic Bracket or the Option N2787A 3D Probe Positioner, which will help you position the probe amplifier in place.

For engineers designing and debugging the latest interface standards, the MX0104A Performance Verification and Deskew Fixture for InfiniiMax Probes offers the highest accuracy and signal integrity in the industry.
