DP0010A DifferentialActiveProbe, 250 MHz

Product Overview

Keysight DP0010A is a member of the DP001xA series of DifferentialActiveProbes with a 250 MHz bandwidth. These Probes can provide excellent general-purpose DifferentialSignalsMeasurement for today's various high-speed power-related Measurements (Such as Motor drive, automotive Differential bus Measurement and high-speed digital system design).

Bandwidth: 250 MHz

Maximum Differential range (DC and AC peak): ±42 V

Maximum Differential range is ±4.2 V at 17:1 auto-attenuation range

Maximum Differential range is ±42 V at 85:1 auto-attenuation range

Input impedance: 1.7 MΩ / 1.5 pF

Cable length: 1.3 meters

Compatible Oscilloscopes

Keysight InfiniiVision 3000T X, 4000 X and 6000 X Series

Keysight Infiniium EXR, MXR and S Series

Keysight Infiniium UXR, V, Z, Q and 90000 X series, requires Using Keysight N5442A Adapter

Each DP0010A Series DifferentialActiveProbe is shipped in a hard plastic carrying case and comes with the following standard accessories:

One pair of jacked Y-wires (2 pieces)

One pair of solder-in Y-wires (2 pieces)

90o ground wire with jack (1 piece)

Micro Circuit Hook Test Clips (2 pcs.)

Adjustable spot test Probe (2 pieces)

Probe storage box (2 pieces)

Cylindrical pins (10 pcs.)

For engineers designing and debugging the latest interface standards, the DP0010A DifferentialActiveProbe, 250 MHz offers the highest accuracy and signal integrity in the industry.
