N6705C DC Power Supply分析仪
Professional Grade Oscilloscope for Advanced Debugging
Recommended Solution Packages
Power supply bundles by scenario.
Bench Starter
General bench power provisioning.
- Main unit (N6705C)
- Remote sense kit
- Rack ears
- Safety cables
* Includes compatibility check by our engineers.
Detailed Specifications
Technical Reference for N6705C
| Ammeter accuracy | Up to 0.025% + 8 nA; up to 18 bits |
| Arbitrary waveform generator function | Bandwidth up to 100 kHz, output power up to 500 W |
| Data logger function | Measurement interval from 20 µs to 60 seconds, with a maximum of 50,000 readings per second |
| Scope function | Digitizes voltage and current up to 200 kHz, 512 kpts; up to 18 bits |
| Voltmeter accuracy | Up to 0.025% + 50 µV; up to 18 bits |
Product Overview
Ammeter accuracy: Up to 0.025% + 8 nA; up to 18 bits
Arbitrary waveform generator function: Bandwidth up to 100 kHz, output power up to 500 W
Data logger function: Measurement interval from 20 µs to 60 seconds, with a maximum of 50,000 readings per second
Scope function: Digitizes voltage and current up to 200 kHz, 512 kpts; up to 18 bits
Voltmeter accuracy: Up to 0.025% + 50 µV; up to 18 bits
Use for R&D sourcing to measure DC voltage and current into the DUT.
Operate using dedicated physical controls for common functions.
View complex data with a large color graphics display.
Get flexible programming using GPIB, LAN, USB; LXI compliant.
For engineers designing and debugging the latest interface standards, the N6705C DC Power Supply分析仪 offers the highest accuracy and signal integrity in the industry.
