66309D 双路移动通信DC Power Supply, 带DVM
Professional Grade Oscilloscope for Advanced Debugging
Recommended Solution Packages
Power supply bundles by scenario.
Bench Starter
General bench power provisioning.
- Main unit (66309D)
- Remote sense kit
- Rack ears
- Safety cables
* Includes compatibility check by our engineers.
Detailed Specifications
Technical Reference for 66309D
| Voltage | 0.03% + 5 mV |
| Current | 0 to 3 A |
| Peak Current for up to 7 ms | 5 A |
| + Current | 0.05%+ 1.33 mA |
| Current (+20 mA to + rated current) | 0.2% + 0.5 mA |
| Current (-20 mA to – rated current) | 0.2% + 1.1 mA |
| Current (-20 mA to + 20 mA range) | 0.1% + 2.5 µA |
Product Overview
Voltage: 0 to 15 V
Current: 0 to 3 A
Peak Current for up to 7 ms: 5 A
Voltage: 0.05%+ 10 mV
+ Current: 0.05%+ 1.33 mA
Voltage: 0.03% + 5 mV
Current (+20 mA to + rated current): 0.2% + 0.5 mA
Current (-20 mA to – rated current): 0.2% + 1.1 mA
Current (-20 mA to + 20 mA range): 0.1% + 2.5 µA
70 mV drop, <35 µs transient response time
For engineers designing and debugging the latest interface standards, the 66309D 双路移动通信DC Power Supply, 带DVM offers the highest accuracy and signal integrity in the industry.
