S94572B Broadband Active Load Pull Software
面向高阶调试的专业级示波器
推荐方案套装
面向分析与自动化的软件配置。
分析套件
支持多仪器的离线分析套件。
- 基础许可
- 多仪器连接支持
- 离线分析选件
- 维护计划
* 工程师将进行兼容性核查。
详细规格
S94572B 的技术参考
产品概览
Calculate vector-corrected EVM and ACPR measurements for any user-specified gamma while achieving the wide dynamic range and low residual EVM of PNA-X modulation distortion applications.
User-specified gamma profiles (included with the S1P file import feature) set the variation across the entire modulation bandwidth for each gamma presented to the amplifier.
Using the M9384B dual-channel vector signal generator, gamma can be controlled at all frequencies within the modulation bandwidth.
Active load control is different from passive load pull. In passive load pull, only the gamma at the center frequency of the modulation bandwidth is controllable, while the gamma at other frequencies is uncontrollable.
面向最新接口标准的设计与调试，S94572B Broadband Active Load Pull Software 提供行业领先的精度与信号完整性。
