N7023A Power Point Test Probe, 350?MHz
面向高阶调试的专业级示波器
推荐方案套装
按测量任务配置的探头方案。
高压探头配置
安全高压测量流程。
- 高压探头（N7023A）
- 安全线缆
- 接地弹簧套件
- 收纳箱
* 工程师将进行兼容性核查。
详细规格
N7023A 的技术参考
产品概览
Features
350 MHz bandwidth
1:1 attenuation ratio
SMT clip that allows you to probe capacitors hands-free
Two-conductor adapter for connecting to 2-pin sockets or other accessories
Comes with replacement spring and rigid probe
Comes with short ground spring for better performance
The N7023A power browser probe is suitable for use with the Keysight N7020A and N7024A power probes. The N7023A browser probe utilizes the mechanical components of our popular passive probes to create a convenient browser accessory for the N7020A and N7024A powered probes.
Designed with convenience and ease of use in mind, the N7023A power browser probe features 350 MHz bandwidth and offers a variety of connectivity and probing options. This browser probe has a compact 2.5 mm diameter tip that allows deep probing into compact devices under test. The sharp tips are spring-loaded to help maintain stable contact and prevent the device under test from slipping off. This browser probe comes with a two-lead adapter for connecting to standard 0.1-inch pitch 2-pin connectors or other accessories. It also comes with an SMT clip, allowing you to probe surface mount capacitors hands-free.
The N7023A power browser probe is only compatible with the N7020A and N7024A power probes. To use a browser probe, simply unscrew the main cable from the N7020A/N7024A power probe and replace it with the N7023A power probe.
面向最新接口标准的设计与调试，N7023A Power Point Test Probe, 350?MHz 提供行业领先的精度与信号完整性。
