N5445A InfiniiMax III point probe
面向高阶调试的专业级示波器
推荐方案套装
按测量任务配置的探头方案。
高压探头配置
安全高压测量流程。
- 高压探头（N5445A）
- 安全线缆
- 接地弹簧套件
- 收纳箱
* 工程师将进行兼容性核查。
详细规格
N5445A 的技术参考
产品概览
Features
bandwidth:
30 GHz (typ)
28 GHz (guaranteed)
Tr = 16.2 psec (10%-90%, only for probe with N2803A)
Connectivity:
Z-axis compliance.
Probe tip spacing can be easily adjusted from 20 mil – 125 mil (0.5 mm – 3.1 mm) using the thumb wheel on the probe.
The integrated LED light on the tip illuminates the detection area, making sure everything is visible.
The N5445A InfiniiMax III Viewer (30 GHz) is the best choice for general-purpose troubleshooting of differential signals, with Z-axis compliance and adjustable probe tip spacing from 20 mil – 125 mil. The width between the signal probe tips can be easily adjusted using the thumbwheel on the browser. The integrated LED light on the tip illuminates the detection area, making sure everything is visible. Compatible with all InfiniiMax III probes and amplifiers.
面向最新接口标准的设计与调试，N5445A InfiniiMax III point probe 提供行业领先的精度与信号完整性。
