N2838A InfiniiMax III PCB ZIF Probe, 25 GHz
面向高阶调试的专业级示波器
推荐方案套装
按测量任务配置的探头方案。
高压探头配置
安全高压测量流程。
- 高压探头（N2838A）
- 安全线缆
- 接地弹簧套件
- 收纳箱
* 工程师将进行兼容性核查。
详细规格
N2838A 的技术参考
产品概览
Features
25 GHz bandwidth (using InfiniiMax III N2803A amplifier and N5439A ZIF probe)
Cdiff = 95 fF，Cse = 130 fF
100 kΩ input Rdiff (DC), 1 kΩ input Rdiff (> 10 kHz)
6:1 attenuation ratio, nominal sensitivity
5 mil – 250 mil (or 0.127 mm – 6.35 mm) variable pitch
The N2838A InfiniiMax III PCB ZIF Probe contains a set of 5 ZIF probes and comes with plastic prongs to assist in soldering the probes to the device under test. This probe uses a printed circuit board substrate, making it a very robust and easy-to-use probing solution.
Compatible with InfiniiMax III probe amplifier and N5439A ZIF probe.
The 130 Ω axial resistor on top of the N2838A ZIF probe can be replaced at any time if it becomes worn or damaged.
N2836-68701 is a replacement axial resistor kit for the N2836A and N2838A. Each resistor kit contains 10 resistors.
面向最新接口标准的设计与调试，N2838A InfiniiMax III PCB ZIF Probe, 25 GHz 提供行业领先的精度与信号完整性。
