N7040A Rogowski AC current probe, 23 MHz, 3000 A
面向高阶调试的专业级示波器
渠道分销
快速响应
推荐方案套装
按测量任务配置的探头方案。
高压探头配置
安全高压测量流程。
适用场景： 电力电子
关键参数
耐压等级带宽爬电间距
- 高压探头（N7040A）
- 安全线缆
- 接地弹簧套件
- 收纳箱
* 工程师将进行兼容性核查。
详细规格
N7040A 的技术参考
产品概览
Features
Peak current: 3,000 A peak
Flexible and easy-to-use probe loop
Coil length: 200 mm
Coil cross section (diameter): 4.5 mm
Bandwidth: 3 Hz to 23 MHz
Cable length: 4 meters (plus 4.5 meters from integrator box to oscilloscope)
Powered by battery pack or AC adapter (included)
Compatible with any Keysight oscilloscope equipped with 1 MΩ BNC input
The Keysight N7040A Rogowski coil current probe is designed for measuring AC currents up to 3,000 A and has a bandwidth of 3 Hz to 23 MHz. This probe is extremely easy to use because it features a thin, lightweight, flexible and easy-to-use clip-on Rogowski coil, enabling current measurements deep into hard-to-reach components and tight spaces in circuits under test. It can also measure large AC currents without using a larger sensor.
The N7040A Series is ideal for measuring AC currents masked by large DC currents and can be used to design, debug, and troubleshoot power semiconductor circuits, power supplies, inverters, and electric motors. These probes come with an AC power adapter and 4 AA batteries to power the probe. It can be used with any Keysight oscilloscope equipped with a 1 MΩ BNC input.
Peak current: 3,000 A peak
Flexible and easy-to-use probe loop
Coil length: 200 mm
Coil cross section (diameter): 4.5 mm
Bandwidth: 3 Hz to 23 MHz
Cable length: 4 meters (plus 4.5 meters from integrator box to oscilloscope)
Powered by battery pack or AC adapter (included)
Compatible with any Keysight oscilloscope equipped with 1 MΩ BNC input
The Keysight N7040A Rogowski coil current probe is designed for measuring AC currents up to 3,000 A and has a bandwidth of 3 Hz to 23 MHz. This probe is extremely easy to use because it features a thin, lightweight, flexible and easy-to-use clip-on Rogowski coil, enabling current measurements deep into hard-to-reach components and tight spaces in circuits under test. It can also measure large AC currents without using a larger sensor.
The N7040A Series is ideal for measuring AC currents masked by large DC currents and can be used to design, debug, and troubleshoot power semiconductor circuits, power supplies, inverters, and electric motors. These probes come with an AC power adapter and 4 AA batteries to power the probe. It can be used with any Keysight oscilloscope equipped with a 1 MΩ BNC input.
面向最新接口标准的设计与调试，N7040A Rogowski AC current probe, 23 MHz, 3000 A 提供行业领先的精度与信号完整性。
