U2021XA 50 MHz to 18 GHz USB 峰值和平均Power Sensor
面向高阶调试的专业级示波器
推荐方案套装
按场景配置的功率传感器方案。
校准配置
精确射频功率校准流程。
- 功率传感器（U2021XA）
- USB 功率计基座
- 校准参考件
- 射频线缆
* 工程师将进行兼容性核查。
详细规格
U2021XA 的技术参考
| Power | -30 to +20 dBm |
产品概览
Frequency range of 50 MHz to 18 GHz
Wide dynamic range of -30 to +20 dBm (peak/gated), -45 dBm to +20 dBm (average only mode)
30 MHz video bandwidth and single shot real-time capture at 80 Msample/sec per second
Internal zeroing & calibration
High measurement speed of up to 25,000 readings/second (free run/fast buffer mode)
Your instrument now comes with the BenchVue Basic Power Meter/Sensor Control and Analysis App (BV0007B). The BenchVue software simplifies the process of connecting, controlling instruments, and automating test sequences. Download the BenchVue Basic App (BV0007B) for free to efficiently manage your power meter/sensor instruments
面向最新接口标准的设计与调试，U2021XA 50 MHz to 18 GHz USB 峰值和平均Power Sensor 提供行业领先的精度与信号完整性。
